C-Band Receive

7894D-3900/4200

Product Specifications

General Parameters:
Application:	WiMAX, Radar & Transmit band Reject Filters
Passband (MHz):	3900/4200
Passband Loss:	0.75 dB TYP @ Fo 0.25 dB TYP ROLL OFF @ PASSBAND EDGES
VSWR / Return Loss:	1.285:1 MAX / 18 dB MIN
Dimensions (Inches):	158 mm x 98.4 mm x 69.85 mm
Rejection:	See PDF
Rejection 2:	35 dB @ 3845 / 4255 MHz
Receive Band (MHz):	3900 - 4200
Insertion Loss:	0.75 dB
Passband Edge Roll-off:	0.25 dB
Return Loss:	18 dB MIN
Flanges:	CPR229G (IN) / CPR229F / OUT
Finish:	WHITE GLOSS PAINT
