C-Band Receive

7894D-3780/4200

Product Specifications

General Parameters:
Application:	WiMAX, Radar & Transmit band Reject Filters
Passband (MHz):	3780/4200
Passband Loss:	1.0 dB MAX
VSWR / Return Loss:	1.33:1 MAX / 17 dB MIN
Group Delay Variation:	8 nS TYP
Dimensions (Inches):	146.1 mm x 98.4 mm x 69.85 mm
Rejection:	See PDF
Rejection 2:	10 dB @ 3725 MHz, 30 dB MIN @ 3700 / 4325 MHz
Weight Lbs:	1.13 kg
Receive Band (MHz):	3780 - 4200
Insertion Loss:	1 dB
Return Loss:	17 dB TYP
Flanges:	CPR229G (IN) / CPR229F / OUT
Finish:	WHITE GLOSS PAINT
