C-Band Receive

7894D-3740/4160

Product Specifications

General Parameters:
Application:	WiMAX, Radar & Transmit band Reject Filters
Passband (MHz):	3740/4210
Passband Loss:	2.0 dB MAX 1.3 dB TYP
VSWR / Return Loss:	1.33:1 MAX / 17 dB MIN
Dimensions (Inches):	148.1 mm x 98.4 mm x 69.85 mm
Rejection:	See PDF
Rejection 2:	25 dB @ 3690 / 4210 MHz
Receive Band (MHz):	3740 - 4160
Insertion Loss:	2.0 dB MAX 1.3 dB TYP
Return Loss:	17 dB MIN
Flanges:	CPR229G (IN) / CPR229F / OUT
Finish:	WHITE GLOSS PAINT
