C-Band Receive

7894D-3600/4050

Product Specifications

General Parameters:
Application:	WiMAX, Radar & Transmit band Reject Filters
Passband (MHz):	3600/4200
Passband Loss:	0.4 dB TYP @ Fo 0.5 dB APPROX ROLL OFF @ PASSBAND EDGES
VSWR / Return Loss:	1.33:1 MAX / 17 dB MIN
Group Delay Variation:	8 nS TYP
Dimensions (Inches):	146.1 mm x 98.4 mm x 69.85 mm
Rejection:	See PDF
Rejection 2:	25 dB @ 3550 / 4100 MHz, 60 dB @ 3450 / 4200 MHz
Weight Lbs:	1.13 kg
Receive Band (MHz):	3600 - 4050
Insertion Loss:	0.4 dB
Passband Edge Roll-off:	0.5 dB
Return Loss:	17 dB MIN
Flanges:	CPR229G (IN) / CPR229F / OUT
Finish:	WHITE GLOSS PAINT
