C-Band Receive

7893D-3710/4210

Product Specifications

General Parameters:
Application:	WiMAX, Radar & Transmit band Reject Filters
Passband (MHz):	3710/4210
Passband Loss:	0.4 dB TYP @ Fo 0.5 dB APPROX ROLL OFF @ PASSBAND EDGES
VSWR / Return Loss:	1.5:1 TYP / 14 dB TYP
Group Delay Variation:	8 nS TYP
Dimensions (Inches):	146.1 mm x 98.4 mm x 69.85 mm
Rejection:	See PDF
Rejection 2:	25 dB @ 3660 / 4260 MHz
Weight Lbs:	1.13 kg
Receive Band (MHz):	3710 - 4210
Insertion Loss:	0.4 dB
Passband Edge Roll-off:	0.5 dB
Return Loss:	14 dB TYP
Flanges:	CPR229G (IN) / CPR229F / OUT
Finish:	WHITE GLOSS PAINT
