C-Band Receive

7893D-3400/4200

Product Specifications

General Parameters:
Application:	WiMAX, Radar & Transmit band Reject Filters
Passband (MHz):	3400/4200
Passband Loss:	1.0 dB MAX
VSWR / Return Loss:	1.44:1 MAX / 17 dB MIN
Dimensions (Inches):	125 mm x 98.4 mm x 69.85 mm
Rejection:	See PDF
Rejection 2:	25 dB @ 3300 / 4300 MHz
Receive Band (MHz):	3400 - 4200
Insertion Loss:	1.0 dB
Return Loss:	17 dB MIN
Flanges:	CPR229G (IN) / CPR229F / OUT
Finish:	WHITE GLOSS PAINT
