X-Band Receive

16603B

16603B
Datasheet

Product Specifications

General Parameters:
Passband: 7.25 - 7.75 GHz
Insertion Loss: 0.2 dB
VSWR (Max): 1.25:1
Rejection: 90 dB Min
Flanges: WR112 Cover, WR112 Grooved
Weight: 1.82 Kg
Dimensions: 514mm x 63mm x 95mm
Finish: Flat Black Lacquer
Reject Band: 7.9 - 8.4 GHz
Pressurization: Sealed TO 5 PSIG
Power: 100 Watts
