C-Band Receive

11383-3625/4200

11383-3625/4200
Documents

Product Specifications

General Parameters:
Application: WiMAX, Radar & Transmit band Reject Filters
Passband (MHz): 3625/4200
Passband Loss: 1.25 dB MAX
VSWR / Return Loss: 1.44:1
Dimensions (Inches): 136.5 mm x 98.4 mm x 69.85 mm
Rejection: See PDF
Rejection 2: 40 dB APPROX @ 3550 MHz
Receive Band (MHz): 3625 - 4200
Insertion Loss: 1.25 dB MAX
Flanges: CPR229G (IN) / CPR229F / OUT
Finish: WHITE GLOSS PAINT
