C-Band Receive

11383-3550/4150

Product Specifications

General Parameters:
Application:	WiMAX, Radar & Transmit band Reject Filters
Passband (MHz):	3550/4200
Passband Loss:	0.4 dB APPROX @ Fo 0.8 dB TYP @ Passband Edges
VSWR / Return Loss:	1.44:1
Dimensions (Inches):	136.5 mm x 98.4 mm x 69.85 mm
Rejection:	See PDF
Rejection 2:	25 dB @ 3500 / 4200 MHz, 50 dB @ 3450 / 4250 MHz, 70 dB @ 3400 / 4300 MHz
Receive Band (MHz):	3550 - 4150
Insertion Loss:	0.4 dB
Passband Edge Roll-off:	0.4 dB
Return Loss:	14.9 dB
Flanges:	CPR229G (IN) / CPR229F / OUT
Finish:	WHITE GLOSS PAINT
